mini oil press

YZYX60 mini screw oil press, a new generation small-sized oil processing equipment, is developed by Xinyu through summing up several years experience in production practice, combined with the advantages of domestic and foreign large and small oil presses. Firstly the seeds are compressed step by step in squeezing chamber and then, the pressure is further improved in it. The YZYX60 mini oil press has these characteristics accordingly: a. improving high oil yield b. reducing dry cake residual rate c. improving high production rate.
In order to improve the strength and service life of the equipment itself, we use strengthen design in all stress components and adopt stainless steel structure to improve reliability for the equipment in operating.
YZYX60 mini oil press
The YZYX60 mini oil press is suitable for processing rapeseed, cottonseed, soybean, peanut, flax seed, sesame, sunflower seed, palm kernel, etc. It has the features below:

stainless steel structure

small and exquisite

beautiful design

stable and reliable operation

high oil rate and capacity

low consumption

simple operation and maintenance
It is suitable for home used, farm and small oil workshop to choose.
Ⅱ. Technique Parameter
1. Specifications of YZYX60 mini oil press Name of the product Screw oil press Model YZYX60
Power(KW)
4 speed of main-shaft(r/min) 36~42
Measurement L*W*H(mm)
1300*350*1000 Weight(kg) 200kg
Daily processing capacity)(t/24h)
45kgs/h
2. Features of YZYX60 mini oil press
The name of Oil crops Day processing capacity (t/24h) 1 hour processing capacity (kg/h) Dry cake residual oil rate ( ％) rapeseed ≤1.08 ≤45 ≤8.0
cottonseed
≤1
≤42
≤7.5
soybean ≤1 ≤42 ≤7.0
peanut
≤1.08
≤45
≤8.0
Notes: 1. It is the normal phenomenon that actual results are different with the parameters in the above table for the reasons of different varieties, quality and oil length of oil plants and operating conditions in local areas
2. The day processing capacity of the above means the first time oil volume with cooked pressing
3. If you choose the cold way, the second time oil volume is the half of the fist time and the like.
Ⅲ. Structure and Working Principle
1. Structure (Fig.1)
The screw oil press is composed of a retarding mechanism, a feeding mechanism, a pressing cage body, a squeezing screw main shaft and bracket base.
2. Working Principle
Firstly the preprocessed oil plants enter into squeezing chamber from hopper when the press operating and then the oil is separated from oil plants and eliminated from pressing bar joints and pressing ring oil line at last under comprehensive effects of pressure which changes from big to small in the volume of squeezing chamber, driving force of spiral, resistance of multi lobe arc curve in pressing ring and interaction friction force between oil plants.
